6 Cree XHP35
High-Power 6x Cree XHP35 LED Module – 48mm Aluminum PCB, 3S2P Array, 6500K Cool White, 2.0W/m.k Thermal Conductivity
Engineered for extreme performance, this 6-die LED module utilizes six authentic Cree XHP35 emitters mounted on a premium 48mm aluminum substrate. Unlike standard single-die modules, this unit is wired in a 3-Series 2-Parallel (3S2P) configuration, offering a perfect balance of high voltage compatibility and current capacity.
The 1.5mm thick aluminum PCB boasts a thermal conductivity of 2.0W/m.k, ensuring rapid heat dissipation to maintain lumen output and extend the lifespan of the XHP35 chips. Whether you are building a high-performance flashlight or an industrial light engine, this module delivers reliability and precision.
Feature | Specification |
|---|---|
LED Chip Type | 6× Cree XHP35 (High-Efficiency Emitter) |
Circuit Configuration | 3 Series 2 Parallel (3S2P) |
Color Temperature | 6500K (Cool White / Daylight) |
PCB Material | Aluminum Substrate (MCPCB) |
PCB Dimensions | Diameter: 48mm |
PCB Thickness | 1.5mm |
Thermal Conductivity | 2.0 W/m.k (High Efficiency Heat Dissipation) |
Mounting | Standard multi-hole design for versatile installation |
Superior Thermal Management: The 2.0W/m.k thermal conductivity of the 48mm aluminum base prevents thermal throttling, ensuring the XHP35 chips operate at peak efficiency.
Flexible Driving Options: The 3S2P wiring allows for versatile driver matching, suitable for both high-voltage/low-current and lower-voltage/high-current setups depending on your specific binning.
Precision Manufacturing: Features clearly marked positive (+) and negative (-) electrodes and standard mounting holes, simplifying the assembly process for DIY enthusiasts and manufacturers alike.
Safety & Insulation: Designed with high insulation performance and pressure resistance, making it safe for use in enclosed industrial fixtures or high-vibration automotive environments.
